3 Phase 3 Wire High Power Resistor Load Bank For Australia Generator Testing

Brand Name : KAIXIANG

Model Number : AC10.5KV-1800KW

Certification : ISO9001

Place of Origin : HEBEI CHINA

MOQ : ONE SET

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,

Supply Ability : 10 SET ONE MONTH

Delivery Time : ONE MONTH AFTER GET DEPOSIT

Packaging Details : WOODEN CASE

Resistive Load : 100KW*2.200KW*1.400KW*2.600KW*1

Rating Voltage/Frequency : 10.5kV/50Hz, 3 phase 3 wire

Load Tolerance (overall) : ±3%

Fan &Control Voltage : External AC 3 phase 4 line, 380V/50Hz

Size : 6058 * 2438 * 2591 mm

Max load power : 1800 KW

Contact Now

In Australia 10.5KV 1800KW Medium Voltage Load Bank For Generator Testing

Product Description

1. our load bank an accurately test output power and load capacity with all kinds of generators.

2. System consists of testing/control and load bank, mainly includes AC load bank, data capture system, auto load/unload control system, heat dissipation device, assist control and PC software.

3. User can control load bank through local control panel, also through software


Technical Parameters

Rating Voltage/Frequency 10.5kV/50Hz, 3 phase 3 wire
Rated power 1800kw
Max load power 30MW
Load Resolution Resistive Load: 100KW*2.200KW*1.400KW*2.600KW*1
PF(Power Factor) 1
Load Tolerance (each step) ±5%
Load Tolerance(overall) ±3%
Display Precision 0.5 class
Control Power 380VAC/50Hz,
Weight About 8000kgs/set
Wire Connection

Load power supply input——Copper bar (star coupling)

Control power supply input——Connector-bar
Size 6058*2438*2591mm


Technology Advantages

1. Communication Mode:RS485/ USB or RS232 interface for communication.

2. Load Mode: manual load or automatic load

3. Manual Load: input power and power factor, and load according to the preset value.

4. Automatic Load: set several load stages and duration, then complete the process according this stages automatically. 0%- 25%,- 50%,- 75%, -100%


Application

1. Manufacturers of standby power generators commonly use load banks to test and tune newly assembled units

2. generator has been set up in a test cell within the factory, a test engineer uses the load bank to apply a discrete, selectable electrical load to the generator and measure the response stability and endurance.

3. During this process, the test engineer calibrates and adjusts the generator performance to ensure it meets the intended product specifications and tolerances.

3 Phase 3 Wire High Power Resistor Load Bank For Australia Generator Testing
